1. ST2119-AS2 Tool set for electrical connectors and wiring systems;
2. All designed according to M22520/2 standard;
3. Meet the crimping of 20-32AWG wires;
4. Applicable to the crimping and positioning of 20#, 22#, 22D# terminals in military connectors such as US military standards 38999, 24308, 50151, 26482, etc.;
5. Contains 1 crimping tool, 37 positioners, and 1 go/no-go gauge.

1. JST1162-ASF1 Tool set for electrical connectors and wiring systems;
2. All designed in accordance with M22520/1 standard;
3. Meet the crimping of 12-26AWG wires;
4. Applicable to the crimping and positioning of 12#, 16#, and 20# terminals in military connectors such as US military standards 38999, 24308, 50151, 26482, etc.;
5. Contains 1 crimping tool, 17 positioners, and 1 go/no-go gauge.

1. Compatible wire range​​: 20-14AWG (0.5-2.0mm)
2.​​ Brass with nickel plating - tin surface finish​​
3. ​​Rated current​​: 13.5A

1. Wire Range: 20-14AWG (0.5-2.0mm²)
2. Nickel-plated with Green Identification Ring
3. Rated Current: 13A

1. Wire Range: 18-16 AWG (0.75-1.50mm²);
2. Brass, Nickel-Plated Surface;
3. Rated Current: 14A

1. Designed according to MIL-M81824/1-1 standard
2. Compatible with 16-20AWG wires
3.​​Operating temperature range: -55°C to +150°C;​​
4.​​Waterproof grade: IP68;​​
5. Suitable for on-site wire connection, electrical maintenance, etc

1. IP67-rated, enhanced waterproof performance;
2. Connector positions: 2-pin;
3. Compatible with stamped terminals: 282403-1/282110-1/282466-1; 282404-1/282109-1/282465-1;
4. Wire range: 0.35-2.50mm²;
5. Interchangeable with market-standard equivalents.

1.Compatible with​​:JRready: JRN009-TBM/JRN009-TBF；CJ: C3030M-TP/C3030F-TP-A, C3030M-GP/C3030F-GP-A；Molex: 4303*-001/4303*-002/4303*-003/4303*-0007/4303*-0008/4303*-0009；​​NOTE​​: When * = 0, P/N is ​​SOCKET contact​​; when * = 1, P/N is ​​PIN contact​​.
​​2.2 die openings​​, compatible wire range: ​​20AWG ~ 24AWG​​.
3.​​Ratcheting mechanism​​ for one-step crimping, ensuring consistent crimp quality.
4.TPR handles​​ for ergonomic grip and durability.

1. Compatible wire range: 16-28AWG;
2. Supports stamped sockets;
3. Connection type: Wire-to-wire;
4. Number of positions: 4;
5. Rated voltage: 250V AC/DC, rated current: 9A;
6. Compatible with market-standard products of the same specification.

1.Compatible with 14-18AWG wires
2.Compatible with crimp terminals
3.Connection type: Wire-to-wire
4.Connector positions: 2-pin
5.Rated voltage: 500V AC/DC, Rated current: 16A
6.Removable terminals

1. Compatible with 14-20AWG wire；
2. Compatible with 16 AWG ring terminals and stamped terminals；
3. Connection Type : Wire to Wire；
4. Number of Positions : 2 positions；
5. Rated Voltage ：250V AC/DC，Rated Current ：13A；
6. Market Compatibility​​: Compatible with products of the same specifications on the market.

1. For SUPERSEAL 1.5 Series Terminals
2. 3 Cavities for Different Wire Ranges: 22-20AWG (0.35-0.50mm²), 18AWG (0.75-1.0mm²), 16AWG (1.5mm²)
3. Compatible with JRready ACT-LY Crimp Tool Frame
