JRready JRN002-TBM-H Terminal

1.Wire range: 20-14 AWG (0.5-2.0 mm²)
2.Mating pin: JRN002-TBF-H
3.Nickel-plated brass with tin finish
4.Rated current: 12A
Contact Us
Brand JRready Part Number JRN002-TBM-H
Category JRN002 (5.03) Series Colour Silver
Material Brass with nickel plating - tin surface finish​ Dimension Length: 22.05mm, Diameter: 2.3mm
Country of Origin China Weight 0.32g
Application Suitable for use in refrigerators, washing machines, electric vehicles, computer mainframes, etc.
Working Temperature -40-105℃ Working Pressure /
Rated Voltage 250V Rated Current 12A

Product Introduction
