JRreadyP703（86-2）（M22520/7-03） Fixed Locator

1. Positioners of various specifications for military standard M22520/7 series
2. Used together with military standard M22520/7-01 crimping pliers
3. Standard specifications for standardized precision crimping
Contact Us
Brand JRready Part Number P703（86-2）（M22520/7-03）
Category M22520/7 Series Positioner Colour Green
Material Stainless Steel Dimension Ø23.62*22.23mm
Country of Origin China Weight 8.83g
Application Compatible with terminals M39029/4-111, /5-116, /11-146, /12-150, /29-212, /30-218, /31-228 THRU -233, /32-247 THRU -252, /123-676, /124-681, /4-112, /5-1 17



Product Introduction
